Technical Specification:

Rated Voltage :

660V, 3 Phase or 600V DC

Rated Current :

Up to 630A

Rated frequency:

50/60 Hz

Short time withstand current :

Upto 50 kA

Standard :

IEC 61439-1&2

Dimension : (mm )

Width  600

Depth  250/350

Height     700/900/1100/1300/1600

  Features:

  • Bolted & Welded Design.

  • Possibility of extension at both ends .

  • Floor Standing and Wall Mounted Surface Type versions available.

  • Provision of cable entry from top & bottom.

  • Complete shrouding of live parts.

  • Protection Class IP55 for outdoor installation  (on Request).

  • Safe Operation.

  • Negligible maintenance.

  • Paint thickness = 80-100 microns
